Floor tile screen
HD LED INTERACTIVE DANCING FLOOR LED SCREEN
Description
- ✓ Application: Interactive dance floors, stages, exhibitions, and event spaces.
- ✓ Brightness: 4500-5500cd/m² optional for clear and vivid image quality.
- ✓ Protection: IP65 front and back design for reliable floor use.
- ✓ Pixel Pitch: P1.25 / P2.5 / P3.91 / P4.81 / P5.2 / P6.25 available.
- ✓ Maintenance: Front and rear service for convenient installation and repair.
- ✓ Performance: Smooth image quality with stable ICN1065 driving solution.
- ✓ Viewing Angle: Wide viewing angle for better audience visibility.
- ✓ Lifetime: 100,000 hours long service life.
Get a Quote
Interested in this product? Contact our team for pricing, customization options, and technical specifications.
Categories
Product Details
Specifications
Technical Specifications
Detailed technical parameters across all available models.
| ITEM | HD LED INTERACTIVE DANCING FLOOR LED SCREEN | |||||
|---|---|---|---|---|---|---|
| Product model | SJ-P1.25 | SJ-P2.5 | SJ-P3.91 | SJ-P4.81 | SJ-P5.2 | SJ-P6.25 |
| Pixel pitch | 1.25mm | 2.5mm | 3.91mm | 4.81mm | 5.2mm | 6.25mm |
| Physical density | 640000dots/m² | 160000dots/m² | 65536dots/m² | 43264dots/m² | 36864dots/m² | 25600dots/m² |
| LED Package | SMD 1010 (3in1) | SMD 1415 (3in1) | SMD 1921 (3in1) | SMD 1921 (3in1) | SMD 1921 (3in1) | SMD 1921 (3in1) |
| Module size | 250mm*250mm | |||||
| Modules resolution | 200*200 | 100*100 | 64*64 | 52*52 | 48*48 | 40*40 |
| Modules weight | 0.8KG | |||||
| Driving method | 1/60S | 1/16S | 1/16S | 1/13S | 1/6S | 1/10S |
| Interface definition | HUB-16P | |||||
| Cabinet size | 500mm*500mm*1000mm | |||||
| Cabinets weight | 10KG/24KG | |||||
| cabinets resolution | 400*400 / 400*800 | 200*200 / 200*400 | 128*128 / 128*256 | 104*104 / 104*208 | 96*96 / 96*192 | 80*80 / 80*160 |
| brightness(cd/m²) | 600cd/m² | 800cd/m² | 4000cd/m² | 4500-5500cd/m² | 4500-5500cd/m² | 4500-5500cd/m² |
| Power consumption | Max: ≤800W/m², Average: ≤450W/m² | |||||
| Refresh rate | ICN1065 Driving IC | |||||
| Viewing angle Level | H: ≥160°Optional, V: ≥120°Optional | |||||
| Viewing distance | 2-10m | 3-30m | 4-40m | 5-50m | 5.5-60m | 65-80m |
| Temperature | Working: -25℃~60℃, Storage: -35℃~80℃ | |||||
| Humidity | 10%~90% | |||||
| Working voltage | Input: AC 100V~240V, 50Hz/60Hz, Output: DC 5V | |||||
| Maintenance method | Front/Back service | |||||
| Protection grade | Front: IP65, Back: IP65 | |||||
| Lifetime | 100000 Hours | |||||
